COURSE DETAILS

We are good in CATIA training

CCUBE TECHNOLOGY providing Courses are designed after a deep research with industry experts, Placement Officers, Technical Heads. These courses are designed and made as per industry standards and are planned with such a way that the job seekers or students must get a job after successful completion of the training course. These training courses are full of hands-on project practicals, personality development and resume writing sessions, mock tests, exams, interviews.

Checkout some our placements training

Catia is CAD tool and can be used for different design stages. You can draw your concepts on it, modify them, simulate them, identify problems and finally detail them to go the production. Catia has different modules like Part design, Surface design, Assembly design, Composite Structure design, Sheet metal design etc. Definitely these are more than one requires. Mostly Catia is used in Aerospace and Automotive industry.

  • To improve the quality of design.
  • To increase the productivity of the engineer.
  • To create a table/database for manufacturing.
  • To improve communication & interpretation through documentation

The main objective of the Training is to equip students with not just technical training but also much-needed career assistance. With its placement support, C Cube Technologies assists students in getting placed in top MNCs.

  • The software is developed by the French company Dassault Systems. AVIONS MARCEL DASSAULT, the French aircraft manufacturer, started CATIA as an in-house development during 1977, at that time customer of the CADAM software to develop Dassault’s Mirage fighter jet. Later on, aerospace, automotive, shipbuilding, and other industries adopted CATIA. CATIA was initially named in French as CATI (Conception Assistée Tridimensionnelle Interactive); it was renamed in 1981 when the company Dassault Systems created a subsidiary to develop and sell and signed a non-exclusive distribution agreement with IBM. In 1984, the Boeing Company chose CATIA V2 as its major 3D CAD tool, which became its largest customer.

  • In 1988, it was ported from mainframe computers to the UNIX platform. In 1990, General Dynamics Electric Boat Corp chose CATIA as its main 3D CAD tool for the designing of the U.S. Navy’s Virginia class submarine. Also, Lockheed was selling its CADAM system worldwide through the channel of the company IBM since 1978. In 1992, CADAM was purchased from the company IBM, and the next year CATIA CADAM Version 4 was published. In 1996, including IBM AIX, Silicon Graphics IRIX, Sun Microsystems SunOS, and Hewlett-Packard HP-UX, it was ported from one to four UNIX operating systems. In 1998, the 5th version of CATIA was released and was an entirely rewritten version of CATIA with support for UNIX platform, Windows NT and Windows XP (since 2001).

  • In the years prior to 2000, problems caused by incompatibility between versions of CATIA V4 &CATIA V5 led to $6.1B in additional costs due to several years of project delays in the production of the Airbus A380. In 2008, Dassault Systems released CATIA V6. While the server of CATIA is able to run on Linux, AIX and Microsoft Windows, client support for any operating system other than Microsoft Windows was dropped by Dassault Systems. In 2010 November, the French company Dassault Systems launched CATIA V6R2011x, the new and latest release of its PLM 2.0 platform, while continuing to support and improve its CATIA V5 software for the bugs in order to bring the updates and modified version of CATIA. In June 2011, Dassault Systems launched V6 R2012. In 2012, Dassault Systems launched V6 2013x. In 2014, Dassault Systems launched 3DEXPERIENCE Platform R2014x and CATIA on the Cloud, a cloud version of the same software.

    CATIA Syllabus

  • INTRODUCTION TO CATIA & SKETCHER WORKBENCH OVERVIEW
  • SKETCHER WORKBENCH
  • PART WORKBENCH
  • SKETCH BASED FEATURES
  • DRESS-UP-FEATURES
  • TRANSFORMATION FEATURES
  • WIREFRAME & SURFACE WORKBENCH
  • SURFACES TOOLS
  • DYNAMIC SECTIONING AND GRAPHIC PROPERTIES
  • INSERT BODY,BOOLEAN OPERATIONS
  • USER SELECTION FILTER, APPLY MATERIAL & RENDER
  • WIREFRAME TOOLS
  • OPERATION TOOLS
  • SHEET METAL WORKBENCH
  • ASSEMBLY WORKBENCH
  • DMU KINEMATICS
  • DRAFTING WORKBENCH

Our Projects

CATIA

Mechanical

CATIA

Mechanical

CATIA

Mechanical

CATIA

Mechanical

CATIA

Mechanical
